Power Supply 36V 360W 10A

Description : Model S-350-5 S-350-12 S-350-15 S-350-18 S-350-24 S-350-36 S-350-48 DC output,current 5V 50A 12V 20\\29A 15V 23A 18V 19.5A 24V 14.5A 36V 9.7A 48V 7.3A Wave and noise 75mvp-p 75mvp-p 75mvp-p 75mvp-p 100mvp-p 120mvp-p 150mvp-p Inlet stability ±2% ±1% ±1% ±1% ±1% ±1% ±1% Load stability ±1% ±0.5% ±0.5% ±0.5% ±0.5% ±0.5% ±0.5% Efficiency 78% 83% 83% 83% 84% 86% 86% Adjustable range for DC voltage ±10% ±10% ±10% ±10% ±10% ±10% ±10% Input current 6A/110V 3A/230VAC AC input voltage range 85~132VAC , 47~63Hz , 240~370VDC AC Inrush current Cold-start current 25A/115VAC 50A/230V Overload protection 105%-130% Type: cut output; Reset: automatic recovery Over-voltage protection 115%~135% Setup, rise, hold up time 200ms,100ms,30ms Withstand voltage I/P-O/P: 1.5KVAC; I/P-F/G: 1.5KVAC; O/P-F/G: 0.5KVAC (1 Min) Isolation resistance I/P-O/P, I/P-F/G, O/P-F/G, 500VDC/100MΩ Working temperature and humidity `-10°C~+60°C, 20%~90%RH Safety standards GB4943 UL60950 EN60950 EMC standards GB9254 EN55022 ClassA Overall dimension 215X115X50mm Weight 0.85kgS
