Description:
Input power: DC 7V-30V, recommended below 24
Output voltage: 5V
Output current: 5A Max.
The steering gear is driven by the power supply, which can be directly connected to the steering gear, and can be used as a power supply module when broken
Features:
(1) 7V-30V voltage input
(2) Using synchronous rectification, higher efficiency
(3) Same shape interface as MP2482 Pin2Pin
(4) The capacitor adopts large-capacity ceramic capacitor, which is not easy to be damaged and has lower heat generatio
(5) Large current and large package inductance to further reduce heat generation
SY8205 information: https://oshwhub.com/WeAct-kai-yuan/sy8205fcc-5a-0-6-30v
SY8205 Test Excessive power, appropriately add heat dissipation, in which the inductor generates little heat
5V 5A When running at full load for more than 3 minutes, the temperature is 60°C +
Description:
Input power: DC 7V-30V, recommended below 24
Output voltage: 5V
Output current: 5A Max.
The steering gear is driven by the power supply, which can be directly connected to the steering gear, and can be used as a power supply module when broken
Features:
(1) 7V-30V voltage input
(2) Using synchronous rectification, higher efficiency
(3) Same shape interface as MP2482 Pin2Pin
(4) The capacitor adopts large-capacity ceramic capacitor, which is not easy to be damaged and has lower heat generatio
(5) Large current and large package inductance to further reduce heat generation
SY8205 information: https://oshwhub.com/WeAct-kai-yuan/sy8205fcc-5a-0-6-30v
SY8205 Test Excessive power, appropriately add heat dissipation, in which the inductor generates little heat
5V 5A When running at full load for more than 3 minutes, the temperature is 60°C +
