Description :
Scale up your industrial automation with the Arduino Pro Opta D1608E! Designed to seamlessly integrate with your Arduino Opta ecosystem, this expansion module is the ultimate tool for advanced control, real-time monitoring, and predictive maintenance applications.
This module instantly adds 16 versatile inputs (analog or digital) and 8 robust relay outputs to your setup. Whether you are using the classic Arduino IDE or the professional Arduino PLC IDE (supporting Ladder, FBD, and more), these new I/Os are managed transparently, allowing you to leverage the full power of the Arduino Pro environment.
Why choose the Opta D1608E Expansion?
Massive I/O Capacity: Manage up to 16 signals (0-24V) and switch up to 8 loads of 6A at 230V.
Maximum Scalability: Connect up to 4 modules in a daisy-chain configuration to a single Opta base unit (Lite, RS485, or WiFi) for an impressive total of I/O ports.
Industrial Grade: Born from the partnership between Arduino and Finder, this system combines industrial-grade reliability with the legendary flexibility of Arduino.
Pro Installation: A compact, rugged design specifically engineered for quick and clean DIN rail mounting.
Technical Specifications
Feature
Details
Power Supply
12 to 24 VDC (Screw terminals)
Inputs (x16)
Analog (0-24V, 14-bit) or Digital (up to 300 Hz)
Relay Outputs (x8)
1x NO contact (SPST), 250 VAC / 6 A
Power Consumption
3 W
Indicators
Status LEDs for each relay
Operating Temp
-20°C to +50°C
Dimensions
88.8 x 70 x 61.1 mm
Programming & Communication
The Opta D1608E fits perfectly into your existing workflow:
- Arduino IDE 2.0 : For smooth C++ programming.
- Arduino PLC IDE: Perfect for professionals using IEC 61131-3 languages (LD, FBD, ST, etc.).
- Arduino Cloud : For secure remote monitoring and global control of your hardware.
Application Examples
Automated Production Lines: Control of complex machinery and conveyors.
Real-time Monitoring: Tracking production metrics and detecting anomalies instantly.
Predictive Maintenance: Analyzing fine analog sensor data to anticipate and prevent system failures.
Note: This expansion module requires an Arduino Opta base unit (not included) to operate. A 12-24VDC power supply must be connected to the screw terminals.
Ready to push your automation even further? Explore the full range of Arduino Pro expansion modules to build a custom industrial controller tailored exactly to your needs.
